Gold anode plate casting machine
Gold anode plate casting machine is a specialized precious metal processing device, mainly used to convert raw materials such as molten gold, crude gold (Au≥85%) and gold-silver alloys (Ag≤30%) into standardized, high-quality gold anode plates. These anode plates are the core raw material for downstream gold electrorefining (the key process to produce 99.99%+ refined gold), and are widely applied in gold refineries, precious metal recycling plants (e.g., e-waste, jewelry scrap processing) and mining facilities-turning gold-rich raw materials into "ready-to-refine" intermediate products to ensure efficient and stable gold electrolysis.
Key Processes
The processing of gold anode plates by this equipment follows a scientific and orderly workflow, covering raw material treatment to finished product forming. The key steps are:
Raw material pre-treatment: Remove impurities (e.g., iron filings, oxide layers) from crude gold or gold-silver alloys to avoid affecting the purity of gold anode plates 2,Molten heating: Heat the pre-treated raw materials to 1250-1400℃ using an intermediate frequency furnace to melt them into molten gold
3,Quantitative casting: Use a servo-driven casting module to pour molten gold into molds in a fixed amount, ensuring uniform weight of each anode plate
4,Cooling and setting: Accelerate the solidification of molten gold in molds through a cooling system, with a solidification time of 30-60s
5,Demolding and transfer: Demold the solidified gold anode plates and transport them to the acid washing station via a transfer trolley
6,Quality inspection: Check the size, weight and surface flatness of gold anode plates to ensure they meet electrorefining requirements
Key Equipment
Gold anode plate casting machine adopts modular integration design, covering melting, casting, weighing, cooling and environmental protection functions. The following are key equipment:
|
S/N |
Item |
|
1. |
IGBT Intermediate Frequency Furnace |
|
2. |
Servo-Driven Casting Module |
|
3. |
Automatic Weighing Equipment |
|
4. |
Double-Layer Fume Hood |
|
5. |
Cooling & Hydraulic Systems |
|
6. |
Gold Anode Plate Transfer Trolley |
|
7. |
Anode Plate Quality Inspection Device |
Sub-Systems of Gold Anode Plate Casting Machine
To ensure the stable operation of the entire casting process, the equipment is supported by dedicated sub-systems:
|
S/N |
Item |
|
1. |
Raw material impurity removal sub-system |
|
2. |
Molten heating control sub-system |
|
3. |
Precision casting adjustment sub-system |
|
4. |
Automatic weighing and metering sub-system |
|
5. |
Smoke collection and environmental protection sub-system |
|
6. |
Electrical control and monitoring sub-system |
Products Produced by the Equipment
The core product of gold anode plate casting machine is standardized gold anode plates, which meet the technical requirements of downstream gold electrorefining. The product quality indicators are as follows:
|
S/N |
Item |
Index |
|
1. |
Gold Anode Plate Purity (%) |
Au≥95% (consistent with raw material purity) |
|
2. |
Gold Anode Plate Size Tolerance (mm) |
±0.3 |
|
3. |
Gold Anode Plate Weight Tolerance (%) |
±0.1 |
|
4. |
Gold Anode Plate Surface Flatness (μm) |
Ra≤1.6 |
Technical Parameters List
|
S/N |
Item |
UOM |
Index |
|
1. |
Production Capacity |
kg/h |
80 (gold anode casting capacity) |
|
2. |
Melting Efficiency |
kg/min |
120kg gold powder melted in 45 minutes (24 anode plates output) |
|
3. |
Melting Time |
min |
7-8 |
|
4. |
Melting Temperature |
℃ |
1250-1400 |
|
5. |
Intermediate Frequency Furnace Power |
Kw |
≤35 |
|
6. |
Furnace Tilt Angle |
℃ |
>90 |
|
7. |
Weighing Accuracy (Automatic Casting Device) |
kg |
≤1 |
|
8. |
Casting Module Positioning Precision |
mm |
0.1 |
FAQ
Q: What payment terms are acceptable?
A: We accept Letters of Credit(LC), Telegraphic Transfers(TT), and cash payments.
Q: Can you provide installation service?
A: Yes, we offer installation services or installation instructions through online or other methods to meet the client's needs.
Q: Can you provide design service to clients?
A: Yes, we can provide customized design services and products according to the client's requirements.
Q: Can the system be customized for different ingot weights?
A: Absolutely. We can adjust mold specifications (e.g., 1kg/2kg/5kg ingots) and weighing parameters according to your needs for ingot weight.
Q: Can the system process other precious metals (e.g., silver powder, gold-silver alloys)?
A: Yes. However, we need a detailed composition analysis report of the raw materials to adjust melting temperature, crucible material, and casting speed, ensuring stable production.
